The UYANG HK10 Polyurethane Timing Belt is a functional timing belt based on the H type inch pitch profile, featuring an integrated K10 polyurethane guide structure molded directly on the belt back.
Structurally, HK10 combines the high load capacity of H type timing belts with a K10 guide profile, enabling stable product support, guidance, and positioning during synchronous conveying.
Unlike glued or welded guides, the K10 profile is formed as part of the belt, providing higher mechanical stability and repeatability.
HK10 belts are widely used in industrial conveying, positioning systems, and OEM machinery where guiding and load stability are required together with power transmission.
The UYANG HK10 Polyurethane Timing Belt is a functional timing belt based on the H type inch pitch profile, featuring an integrated K10 polyurethane guide structure molded directly on the belt back.
Structurally, HK10 combines the high load capacity of H type timing belts with a K10 guide profile, enabling stable product support, guidance, and positioning during synchronous conveying.
Unlike glued or welded guides, the K10 profile is formed as part of the belt, providing higher mechanical stability and repeatability.
HK10 belts are widely used in industrial conveying, positioning systems, and OEM machinery where guiding and load stability are required together with power transmission.
Brand: UYANG BELTING
Model: HK10 PU Timing Belt
Base Profile: H Type (Inch Pitch)
Pitch: 0.500 inch (12.7 mm)
Back Profile: K10 Integrated PU Guide
Material: Thermoplastic Polyurethane (TPU)
Tension Member: Steel Cord / Aramid Cord (optional)
H Type Timing Belt Base (0.500″ Pitch)
Designed for medium to high load industrial transmission.
Integrated K10 PU Guide Profile
Molded as one piece with the belt body for stable guidance and support.
Improved Conveying Stability
Prevents lateral movement and improves product positioning accuracy.
High Mechanical Reliability
No glued or welded guides that may detach during operation.
Durable TPU Construction
Resistant to wear, oils, grease, and industrial environments.
| Item | Specification |
|---|---|
| Tooth Profile | H Type (Inch Series) |
| Pitch | 0.500 inch (12.7 mm) |
| Back Profile | K10 integrated PU guide |
| Standard Widths | 25 / 38 / 50 / 75 mm (custom available) |
| Operating Temperature | −20 °C to +80 °C |
| Belt Construction | TPU body + steel / aramid cords |
| Endless Type | Open End / Endless / Truly Endless |
Guide geometry, height, and spacing can be customized according to application requirements.
Guided synchronous conveyors
Product positioning and transfer systems
Packaging and processing machinery
Industrial automation equipment
OEM machines requiring integrated guiding solutions
HK10 belts are typically selected when a standard H type belt is not sufficient to ensure stable guidance or product positioning.
| Feature | H Type | HK10 |
|---|---|---|
| Base Pitch | 0.500″ | 0.500″ |
| Guiding Function | None | Integrated K10 guide |
| Conveying Stability | Standard | High |
| Structural Integrity | Transmission only | Transmission + guiding |
| Typical Use | Power transmission | Guided conveying & positioning |
Choose HK10 when guiding and positioning functions must be integrated into the timing belt.
Clear structural design: H base + K10 guide
One-piece molded PU construction
Stable pitch accuracy and guiding repeatability
OEM customization based on drawings and applications
UYANG BELTING focuses on function-integrated timing belt solutions, not simple add-ons.
To prepare an accurate quotation, please provide:
Belt width and length
Endless type (open / endless / truly endless)
K10 guide requirements (height, width, spacing)
Product weight and conveying speed
Application environment
