The UYANG T10K13 Polyurethane Timing Belt is a functional timing belt based on the T10 metric trapezoidal profile, featuring an integrated K13 polyurethane guide molded on the belt back.
Structurally, T10K13 combines the stable transmission performance of T10 timing belts with a K13 guide profile designed to provide strong lateral guidance and conveying stability.
The guide is molded as part of the belt body, not glued or welded, ensuring reliable performance under continuous operation.
T10K13 belts are widely used in guided conveying systems, positioning conveyors, and industrial automation equipment where higher guiding strength than K10 is required.
The UYANG T10K13 Polyurethane Timing Belt is a functional timing belt based on the T10 metric trapezoidal profile, featuring an integrated K13 polyurethane guide molded on the belt back.
Structurally, T10K13 combines the stable transmission performance of T10 timing belts with a K13 guide profile designed to provide strong lateral guidance and conveying stability.
The guide is molded as part of the belt body, not glued or welded, ensuring reliable performance under continuous operation.
T10K13 belts are widely used in guided conveying systems, positioning conveyors, and industrial automation equipment where higher guiding strength than K10 is required.
UYANG T10K13 Polyurethane Timing Belt
Brand: UYANG BELTING
Model: T10K13 PU Timing Belt
Base Belt Type: T10 Timing Belt
Pitch: 10 mm
Back Guide: K13 Polyurethane Guide Profile
Material: Thermoplastic Polyurethane (TPU)
Tension Member: Steel Cord / Aramid Cord (optional)
T10 Timing Belt Base (10 mm Pitch)
Proven trapezoidal tooth profile for stable synchronous transmission.
Integrated K13 PU Guide Profile
Stronger and higher guide geometry compared to K10.
Improved Lateral Stability
Effectively prevents belt wandering and misalignment.
One-Piece Molded Construction
No risk of guide detachment during operation.
Durable TPU Material
Resistant to abrasion, oils, grease, and industrial environments.
| Item | Specification |
|---|---|
| Tooth Profile | T10 (Trapezoidal) |
| Pitch | 10 mm |
| Back Guide | K13 integrated PU guide |
| Standard Widths | 25 / 32 / 50 / 75 mm (custom available) |
| Operating Temperature | −20 °C to +80 °C |
| Belt Construction | TPU body + steel / aramid cords |
| Endless Type | Open End / Endless / Truly Endless |
Guide height, width, and position can be customized according to application requirements.
Guided synchronous conveyors
Product positioning and transfer systems
Packaging and processing machinery
Industrial automation lines
OEM equipment requiring belt guidance
T10K13 belts are typically selected when standard T10 belts or T10K10 belts cannot provide sufficient guiding strength.
| Feature | T10K10 | T10K13 |
|---|---|---|
| Base Belt | T10 | T10 |
| Guide Profile | K10 | K13 |
| Guiding Strength | Medium | High |
| Lateral Stability | High | Very High |
| Typical Use | General guided conveying | Heavy-duty guided conveying |
Choose T10K13 when higher lateral forces, heavier products, or longer conveyors are involved.
Clear structure: T10 base belt + K13 guide
One-piece molded guide for high reliability
Stable pitch accuracy and guiding repeatability
OEM customization based on drawings and applications
UYANG BELTING focuses on function-integrated timing belt solutions, not post-assembled add-ons.
To prepare an accurate quotation, please provide:
Belt width and length
Endless type (open / endless / truly endless)
K13 guide dimensions and position
Load, speed, and conveyor layout
Application environment
📩 Contact UYANG BELTING for professional T10K13 PU timing belt solutions.
