White PTFE coated fiberglass fabric is a premium high-temperature composite material designed for clean, controlled, and food-grade environments. Manufactured from high-strength fiberglass cloth and coated with refined PTFE resin, this material combines excellent thermal stability, non-stick performance, and mechanical durability with a clean white surface appearance.
White PTFE coated fiberglass fabric is a premium high-temperature composite material designed for clean, controlled, and food-grade environments. Manufactured from high-strength fiberglass cloth and coated with refined PTFE resin, this material combines excellent thermal stability, non-stick performance, and mechanical durability with a clean white surface appearance.
Food processing conveyors and baking systems
Heat sealing machines and packaging lines
Pharmaceutical and clean production environments
Shrink tunnels and thermal bonding equipment
Plastic thermoforming and heat press applications
Release sheets for rubber vulcanization
Electrical insulation and high-temperature surface protection
The white finish enhances visual inspection, improves cleanliness perception, and is especially suitable for food processing, pharmaceutical, and precision industrial applications where hygiene and surface visibility are essential.
| Model | Color | Max Width(mm) | Thickness (mm) | Weight ( g/sqm) | PTFE Content (%) |
Tensile Strength (N/5CM) |
Remarks |
| YS9008A | White | 1250 | 0.075 | 150 | 67 | 550/500 | |
| YS9010G | White | 1250 | 0.10 | 220 | 53 | 1000/900 | |
| YS9011A | White | 1250 | 0.11 | 220 | 53 | 1000/900 | |
| YS9011AJ | Brown | 1250 | 0.11 | 220 | 53 | 1000/900 | |
| YS9012AJ | Brown | 1250 | 0.12 | 240 | 57 | 1000/900 | |
| YS9023AJ | Brown | 2800 | 0.23 | 490 | 59 | 2200/1900 | |
| YS9030AJ | Brown | 2800 | 0.30 | 620 | 53 | 2500/2000 |
Wide Temperature Range
Continuous working temperature from -60°C to 300°C.
Maintains mechanical strength and dimensional stability even under long-term high-temperature exposure.
Remains flexible at low temperatures without cracking.
Ultra-Smooth, Non-Stick Surface
PTFE surface prevents adhesion of resins, adhesives, oils, chemicals, and food residues.
Easy to clean and reduces production downtime.
Low Friction & Energy Efficient
Friction coefficient as low as 0.05–0.1, allowing smooth material release and reduced drag during conveying or heat sealing.
High Mechanical Strength
Minimal elongation (≤5%) with strong tensile performance.
Maintains stability under tension, pressure, and thermal stress.
Electrical Insulation Performance
Dielectric constant between 2.6–3.0.
Low dielectric loss, suitable for insulation applications.
Chemical & Corrosion Resistance
Resistant to acids, alkalis, organic solvents, and harsh industrial environments.
Food-Grade Compliance
Conforms to FDA and EU LFGB standards, suitable for direct or indirect food contact.
Flame Retardant & UV Resistant
With or without high-temperature adhesive backing
Roll or sheet supply
Custom thickness and width
Anti-static or reinforced versions available
Reliable delivery schedules and warehousing support.
Competitive pricing to maximize overall value.
Diverse options to cater to all market segments.
Flexible MOQ Support with all types of goods;
Personalized logo customization on the products
Provide online technical support for all product usage and installation processes
Quick first response to all inquiry and questions
Provide quality images, Video to enhance sales revenue
Efficient production and ship within 15 days at the fastest.
Generally it is 10-15 days, if peak season, it will be about 15-20 day safter receiving the deposit
1. Confirmed Specification: thickness,color, plies,characteristic, and industry;
2. Samples sending: we send samples for you check.or you send us samples if customized belt.
3. Confirm Order: Signing sales contract after samples confirmed.
4. Deposit: 30% deposit before mass production.
5. Production arranged : we will process the production.
6. Remaining payment: after inspection, balance before shipment.
7. Shipping: we will ship the goods to destination port.
8. Confirm bill of loading/commercial invoice/packing list/certificate of origin;
