The UYANG T5K6 Polyurethane Timing Belt is a functional timing belt based on the T5 metric trapezoidal profile, featuring an integrated K6 polyurethane guide molded on the belt back.
Structurally, T5K6 combines the compact design of T5 timing belts with a K6 guide profile that provides lateral guidance and improved conveying stability.
The guide is molded as part of the belt body, ensuring reliable performance without the risk of detachment associated with glued guides.
T5K6 belts are typically used in light-duty guided conveyors and compact automation systems.
The UYANG T5K6 Polyurethane Timing Belt is a functional timing belt based on the T5 metric trapezoidal profile, featuring an integrated K6 polyurethane guide molded on the belt back.
Structurally, T5K6 combines the compact design of T5 timing belts with a K6 guide profile that provides lateral guidance and improved conveying stability.
The guide is molded as part of the belt body, ensuring reliable performance without the risk of detachment associated with glued guides.
T5K6 belts are typically used in light-duty guided conveyors and compact automation systems.
Brand: UYANG BELTING
Model: T5K6 PU Timing Belt
Base Belt Type: T5 Timing Belt
Pitch: 5 mm
Back Guide: K6 Polyurethane Guide Profile
Material: Thermoplastic Polyurethane (TPU)
Tension Member: Steel Cord / Aramid Cord (optional)
T5 Base Profile (5 mm Pitch)
Suitable for compact drive systems and small pulleys.
Integrated K6 PU Guide
Designed for light lateral guidance and tracking stability.
Improved Belt Alignment
Reduces wandering in guided conveyor frames.
One-Piece Molded Construction
Higher reliability compared to welded or glued guides.
Durable TPU Material
Resistant to abrasion, oils, and common industrial conditions.
| Item | Specification |
|---|---|
| Tooth Profile | T5 (Trapezoidal) |
| Pitch | 5 mm |
| Back Guide | K6 integrated PU guide |
| Standard Widths | 10 / 15 / 20 / 25 mm (custom available) |
| Operating Temperature | −20 °C to +80 °C |
| Belt Construction | TPU body + steel / aramid cords |
| Endless Type | Open End / Endless / Truly Endless |
Guide height, width, and positioning can be customized according to application requirements.
Small guided conveyors
Compact transfer systems
Light packaging and labeling machines
Automation equipment requiring belt tracking
OEM machinery with narrow belt widths
T5K6 belts are selected when standard T5 belts require additional lateral guidance for stable conveying.
| Feature | T5 | T5K6 |
|---|---|---|
| Base Belt | T5 | T5 |
| Guide Profile | None | K6 |
| Conveying Stability | Standard | Improved |
| Typical Use | Power transmission | Guided conveying |
Choose T5K6 when belt alignment and lateral guidance are required in compact systems.
Clear structure: T5 base belt + K6 guide
Reliable one-piece molded guide
Stable pitch accuracy
OEM customization capability
UYANG BELTING focuses on function-integrated timing belt solutions designed for practical industrial use.
To provide an accurate quotation, please share:
Belt width and length
Endless type (open / endless / truly endless)
K6 guide dimensions and position
Load, speed, and conveyor layout
Application environment
📩 Contact UYANG BELTING for professional T5K6 PU timing belt solutions.
