A compact all-in-one solution for finishing PU timing belts — this machine grinds surfaces and edges while simultaneously washing teeth to deliver clean, precise profiles and a ready-to-use belt every cycle. Built for production lines that demand consistent quality, reduced rework, and faster downstream assembly.
A compact all-in-one solution for finishing PU timing belts — this machine grinds surfaces and edges while simultaneously washing teeth to deliver clean, precise profiles and a ready-to-use belt every cycle. Built for production lines that demand consistent quality, reduced rework, and faster downstream assembly.
Advantages:
One-Pass Finishing
Consistent Tooth Profile
Cleaner, Ready-to-Use Belts
Reduced Rework
Fast Changeover
All-in-One Timing Belt Surface and Edge Grinding with Tooth Washing Machine
This machine can grind both sides of the surface and wash the teeth of the coated rubber / PU timing belt
1 . Suitable for: PU / Rubber sheet or Belt coating products
3. Voltage : 380V 3Phase , 50/60Hz
4. Frequency: 50Hz
5. Structure : Aluminium + Iron + Stainless steel structure, white color
6. Working Width: 5- 150mm
7. Max Working Thick: 20mm
8. Grinding Width : 5~ 150 mm
Key features
Integrated 3-in-1 Operation — surface grinding, edge trimming and tooth washing in one pass.
Precision Control — adjustable grinding depth, edge alignment and wash pressure for repeatable results.
High Throughput — continuous processing suitable for medium to high-volume lines.
Clean Finish — effective debris extraction and flushing ensure residue-free teeth and edges.
Robust Construction — industrial components for long service life and low maintenance.
User-Friendly Interface — PLC touch control, presets for different belt types and quick-change tooling.
Safety & Environmental — enclosed grinding area, dust/wet separation and easy waste disposal.
Typical applications
Final finishing before belt vulcanizing or assembly
Cleaning and profiling belts for high-precision timing systems
Preparing belts for adhesive backing or secondary treatments
