Customized Positive Drive Homogeneous Belts for Demanding Food Processing Applications
UYANG BELTING offers fully customizable, easy-to-clean Positive Drive Homogeneous Belts—ideal for a wide range of food processing environments, including raw meat, fresh produce, frozen foods, and fried products. We provide multiple pitch options such as 25.4mm, 39.7mm, and 50.4mm, along with a variety of surface finishes including smooth, golf pattern, horizontal bar, glossy, and matte. and the thickness, pattern, pitch, width, length could be customized; Meanwhile we could provide Sidewall, Guide, Cleats which are used for Homogeneous belt;
Customized Positive Drive Homogeneous Belts for Demanding Food Processing Applications
UYANG BELTING offers fully customizable, easy-to-clean Positive Drive Homogeneous Belts—ideal for a wide range of food processing environments, including raw meat, fresh produce, frozen foods, and fried products. We provide multiple pitch options such as 25.4mm, 39.7mm, and 50.4mm, along with a variety of surface finishes including smooth, golf pattern, horizontal bar, glossy, and matte. and the thickness, pattern, pitch, width, length could be customized; Meanwhile we could provide Sidewall, Guide, Cleats which are used for Homogeneous belt;
Key Benefits:
Zero risk of fabric contamination – no fabric layer means no hidden hygiene hazards
Cost-effective cleaning and maintenance – save time, water, and labor
Excellent sealing and waterproof performance – reliable in wet and washdown areas
No aging or delamination – long-lasting material integrity
Stable performance at low temperatures – ideal for frozen and chilled food processing
UYANG BELTING easy-to-clean homogeneous belts can effectively inhibit bacterial growth, avoid product contamination during transportation. and provide customers with a safe and healthy operating environment;
Selection reference:
Do not need to change the original mechanical structure. can be installed directly.
Code |
color |
Material |
Hardness |
Antibacterial class |
Thickness(mm) |
Maximumload(kg/m2) |
Working temperature(°C) |
Surface design |
Minimumroll diameter(mm) |
| S00-U20Y/AM | Blue | TPU | 85A | Grade one | 2.0 | 160 | -5/+80 | glossy/matte | 40 |
| S00-W20Y/AM | White | TPU | 85A | Grade one | 2.0 | 160 | -5/+80 | glossy/matte | 40 |
| S00-U30Y/AM | Blue | TPU | 85A | Grade one | 3.0 | 180 | -5/+80 | glossy/matte | 50 |
| S00-W30Y/AM | White | TPU | 85A | Grade one | 3.0 | 180 | -5/+80 | glossy/matte | 50 |
| S00-U30Y/AG | Blue | TPU | 85A | Grade one | 3.0 | 180 | -5/+80 | glossy/golf | 50 |
| S00-U30Y/AS | Blue | TPU | 85A | Grade one | 3.0 | 180 | -5/+80 | glossy/small triangle | 50 |
| H00-DU30Y/AM | Dark Blue | TPU | 50D | Grade zero | 3.0 | 180 | -20/+60 | glossy/matte | 60 |
| H00-DU30Y/AG | Dark Blue | TPU | 50D | Grade zero | 3.0 | 180 | -20/+60 | glossy/golf | 60 |
Reliable delivery schedules and warehousing support.
Competitive pricing to maximize overall value.
Diverse options to cater to all market segments.
Flexible MOQ Support with all types of goods;
Personalized logo customization on the products
Provide online technical support for all product usage and installation processes
Quick first response to all inquiry and questions
Provide quality images, Video to enhance sales revenue
Efficient production and ship within 15 days at the fastest.
Generally it is 10-15 days, if peak season, it will be about 15-20 day safter receiving the deposit
1. Confirmed Specification: thickness,color, plies,characteristic, and industry;
2. Samples sending: we send samples for you check.or you send us samples if customized belt.
3. Confirm Order: Signing sales contract after samples confirmed.
4. Deposit: 30% deposit before mass production.
5. Production arranged : we will process the production.
6. Remaining payment: after inspection, balance before shipment.
7. Shipping: we will ship the goods to destination port.
8. Confirm bill of loading/commercial invoice/packing list/certificate of origin;
