UYANG BELT tubular PU round belt features a unique non-return plug connection system, enabling fast on-site assembly without requiring specialized welding equipment. By inserting the specially designed plug into both ends of the belt, a secure and reliable connection is formed, ideal for frequent disassembly scenarios or emergency repairs. For permanent connections, traditional thermal welding remains fully compatible.
UYANG BELT tubular PU round belt features a unique non-return plug connection system, enabling fast on-site assembly without requiring specialized welding equipment. By inserting the specially designed plug into both ends of the belt, a secure and reliable connection is formed, ideal for frequent disassembly scenarios or emergency repairs. For permanent connections, traditional thermal welding remains fully compatible.
Quick Installation – No special tools required
Exceptional Flexibility – Adapts to dynamic and changing needs
Nem vedligeholdelse – Minimizes downtime and servicing costs
High Performance – Durable and stable operation
Omkostningseffektiv – Reduces overall operational expenses
Equipment Maintenance: Streamlines production line maintenance and reduces downtime
Modular Systems: Perfect for automation equipment requiring quick replacement of conveyor units
Temporary Conveyor Systems: Ideal for exhibition setups or temporary production lines
Food & Pharmaceutical Industries: Supports fast disassembly and cleaning in hygienic environments
Plug connection zone is specially reinforced, capable of withstanding ≥80% of the belt’s original tensile strength
Internal guiding grooves ensure plug lock stability
Available in conductive, anti-staticog oil-resistant variants
Extended operating temperature range: -30°C to +80°C
Plug connection is especially recommended in the following scenarios:
✓ Applications requiring disassembly ≥2 times per day
✓ Worksites without professional welding staff
✓ Systems requiring adjustable belt length
Technical Data:
| Size (mm) | Min. pulley dia. (mm) |
Pull force (1%) kg. |
Min. pulley dia. (mm) |
Pull force (1%) kg. |
Min. pulley dia. (mm) |
Pull force (1%) kg. | |
|---|---|---|---|---|---|---|---|
| O.D. | I.D. | ||||||
| 4.8 | 1.8 | 35 | 0.29 | 43 | 0.37 | 45 | 0.68 |
| 6.3 | 2.4 | 45 | 0.49 | 55 | 0.63 | 60 | 1.15 |
| 8 | 3.2 | 55 | 0.78 | 65 | 1.01 | 75 | 1.83 |
| 9.5 | 4 | 65 | 1.10 | 75 | 1.41 | 85 | 2.52 |
| 12.5 | 5.3 | 85 | 1.88 | 100 | 2.42 | 115 | 4.35 |
| 15 | 5.3 | 100 | 2.88 | 120 | 3.71 | 150 | 6.68 |
| 18 | 7.8 | – | – | – | – | 180 | 8.95 |
| 20 | 7.8 | – | – | – | – | 200 | 11.34 |
The latest 3rd generation quick connector incorporates a memory alloy insert, delivering an instant “plug-and-lock” function. Installation time is reduced by 60% compared to traditional methods. Additionally, FDA-approved food-grade materials og ATEX-certified explosion-proof versions are available for specialized industry needs.
✔ Logistics Sorting Systems – Quick replacement of worn sections to improve maintenance efficiency
✔ Food Packaging Lines – Easy to disassemble and clean, compliant with hygiene standards
✔ Temporary Conveyor Systems – Ideal for exhibitions, construction sites, and other quick setup environments
✔ Automated Production Lines – Modular design facilitates equipment adjustments and upgrades
